| Truck type |
Mercedes Benz ATECO 1523 |
| Wheel base |
4160 mm |
| Line guide |
connected to stearing, pneumatic lifting |
| Compressor |
Kaeser Typ M42, effective air supply 4,25 m³/min at 7 bar |
| Thermoplastic pressure tank |
1x 500 ltr., 1x 300 ltr. |
| Thermal oil heating |
on request gas or diesel |
| Glass bead pressure tank |
2x 120 ltr., upright mounted |
| Extruder |
different flap sizes available |
| Additional equipment |
quick cleaning system for extruder head |
| Outrigger / marker units |
right and left hand side, 600 mm hydraulic side access, pneumatic lifting |
| Operators section |
right and left, near outrigger, panel with all necessary instruments |
| Spray guns |
on request |
| Glass bead equipment |
on request |
| Empty- / total weight |
approx. 9630 kg / 15000 kg |
| Dimensions (L*W*H) |
approx. 8,90 m* 2,50 m* 3,30 m |
